SWIR Polymer Sorter AI Powered Precision Color Sorting Equipment

Name: SWIR Polymer Sorter AI Powered Precision Color Sorting Equipment
Brand: PHOENIX
Price: 1 USD

Wholesale SWIR Polymer Sorter AI Powered Precision Color Sorting Equipment from china suppliers

Brand Name : PHOENIX

Model Number : HPB AI-SWIR Sorter

Place of Origin : Hefei

MOQ : 1

Price : Price Negotiable

Payment Terms : L/C,D/A,D/P,T/T,,

Delivery Time : 5-8 work days

Model : HPB1

Belt Width (mm) : 1200

Air Nozzle : 88

Throughput (t/h) : 1.5~3.0

Air Pressure (MPa) : 0.6~0.8

Power (kW) : 7

Contact Now

HPB AI-SWIR Sorter AI Powered Precision Detection By Color, Polymer, Label And Shape; Recovery Of PET Bottles And Other Plastic Bottles

HPB AI-SWIR Sorter is a superior AI powered sorting solution designed for recycling plants (PET bottle lines) and waste sorting centers (MSW processing plants) to use advanced color and polymer detection to automatically separate PET, HDPE, and other plastics with 99%+ accuracy for efficient recycling

Technical Features

Dual-Sensor Simultaneous Detection
- Superior InGaAs-SWIR Camera System detects polymer types (PET/HDPE/PP, etc.) based on molecular composition
- High-resolution RGB Camera System detects color variations (clear/blue/green/contaminated bottles)
AI Deep Learning
- Automatically classifies bottles, caps, labels and contaminants (metal, silicone)
- Self-learning for new materials and complex patterns (e.g., printed-label bottles)
- Adapts to challenging scenarios (reflective/black/crushed bottles)
High-Performance Belt Sorting
- Modular belt system: 2-6 tons/hour capacity
- 88-224 nozzles with ≤1ms response & ±2mm ejection accuracy
- Modular design of belt width from 1200 to 2800mm (1200/2000/2800) provides processors more flexibility

SWIR Polymer Sorter AI Powered Precision Color Sorting Equipment

Specifications

Model	Belt Width (mm)	Air Nozzle	Throughput (t/h)	Air Pressure (MPa)	Air Consumption (m³/min)	Power (kW)	Unpacked Weight (kg)	Dimension (mm)
HPB1	1200	88	1.5~3.0	0.6~0.8	<3.5	7	4000	9600×2000×2900
HPB2	2000	160	3.0~4.0	0.6~0.8	<6.5	12	5000	9600×3200×2900
HPB3	2800	224	4.0~6.0	0.6~0.8	<9.0	16	6500	9600×4000×2900
