PW RGB Coffee Cherry Sorter
Designed specifically for freshly harvested coffee cherries, this system provides a tailored sorting solution, perfectly suited for high-pressure washing and sterilization processes in coffee primary processing.
Key Features & Technical Highlights
Customized Sorting for Coffee Cherries
Engineered for the physical characteristics of coffee cherries to enable gentle and accurate sorting.
Compact & Easy Deployment
Single-belt sorting system with a compact design, allowing quick installation and integration.
Uniform Feeding for Higher Accuracy
Equipped with a high-capacity waterproof vibrating feeder that spreads cherries into a single layer, minimizing overlap and optimizing optical detection.
Robust & Hygienic Construction
Reinforced food-grade stainless steel structure, with fully sealed scanning unit and control cabinet, resistant to frequent high-pressure washing and chemical sterilization.
Easy Maintenance & Cleaning
Quick-change belt design simplifies daily cleaning and upkeep, meeting stringent food safety standards.
Reliable Humidity Control System
Integrated humidity control ensures stable performance in moist environments and reduces downtime.
Modular Belt Width for Flexible Layout
Belt width options (300/600/1200/1800 mm) covering a range from 300–1800 mm, providing adaptable configuration for different production lines.
AI-Powered Quad-Detection System
- Proprietary AI Deep Learning Algorithm: Continuously improves recognition accuracy through new sample training.
- High-Resolution RGB Camera System: Captures detailed color and texture information.
- High-Brightness LED Lighting: Ensures consistent and even illumination for reliable imaging.
Multi-Feature Defect Detection
- Immature (green) cherries
- Overripe (black) cherries
- Mold-infected (white/gray fungal spots) cherries
- Crushed/cracked cherries
- Shriveled/dried cherries
- Insect-damaged cherries
- Leaf/stem residues
- Other foreign objects
The PW RGB Coffee Cherry Sorter combines durable and sanitary design, intelligent detection technology, and modular flexibility to deliver a stable, efficient, and hygienic automated sorting solution—enhancing raw coffee bean quality and operational productivity for processors worldwide.
Specifications
| Model |
Belt Width (mm) |
Air Nozzle |
Air Pressure (MPa) |
Air Consumption (L/min) |
Voltage |
Power (kW) |
Dimension (mm) |
Unpacked Weight (kg) |
| PW1 |
300 |
64 |
0.6~0.8 |
<1200 |
220V~ 50/60Hz |
3.2 |
3816×1240×1866 |
672 |
| PW2 |
600 |
128 |
0.6~0.8 |
<2400 |
220V~ 50/60Hz |
3.5 |
4340×1811×2144 |
862 |
| PW4 |
1200 |
256 |
0.6~0.8 |
<3600 |
220V~ 50/60Hz |
4.8 |
4519×2411×2144 |
1120 |
| PW6 |
1800 |
384 |
0.6~0.8 |
<3600 |
220V~ 50/60Hz |
6.8 |
4502×3075×2144 |
1425 |
